9V NiMH Battery

9V R3 Square Ni-MH Rechargeable Battery Packs 160mAh 200mAh
16 Years OEM 9V NiMH Pack Factory

9V R3 Square Ni-MH Rechargeable Battery Packs
160mAh / 200mAh Standard Industrial NiMH 8.4V Pack

WJ R3 shell 9V NiMH battery pack, all parameters extracted from official delivery spec WJ-TC-S-53419 & WJ 9V-200 spec docs. Nominal pack voltage 8.4V (6pcs 1.2V cylindrical cells in series), unified outer dimension T17.5 × W26.5 × H48.5mm. Two standard models: L9V-160 (160mAh) / L9V-200 (200mAh). Max 2C continuous discharge (320mA), internal resistance ≤800mΩ, IEC standard ≥500 cycle life. Dual charging mode: 0.1C 16hrs standard slow charge, 0.5C 2.4hrs fast charge with -ΔV & temperature cutoff protection. Operating discharge temp -10~50℃, passed short circuit / vibration / drop safety test. Standard snap metal terminals, OEM custom lead wire for multimeters, smoke alarms, wireless microphones, portable gas detectors.

Get Original Spec & Free Sample

Full Specifications Of 9V R3 Ni-MH Battery Pack (Official Spec Data)

Pack Model Model No. Rated Capacity(mAh) Min Capacity(mAh) Pack Size T×W×H(mm) Single Cell Size(mm) Std Charge Fast Charge Pack Weight(g) IR(mΩ) Max Discharge Cutoff Voltage(V) IEC Cycles Discharge Temp Core Application
9V R3 Pack WJ L9V-160-R4 160 160 17.5×26.5×48.5 Φ10×43 16mA / 16h 80mA / 2.4h 28 ≤800 320mA (2C) 7.0 ≥500 -20℃ ~ 50℃ Multimeter, CO Detector
9V R3 Pack WJ L9V-200-R3 200 190 17.5×26.5×48.5 Φ10×43 20mA / 16h 100mA / 2.4h 35.5 ≤780 400mA (2C) 7.0 ≥500 -20℃ ~ 50℃ Wireless Mic, Smoke Alarm

Core Advantages Of R3 9V Ni-MH Battery Pack (Per Spec)

9V Capacity Options

160/200mAh Two Standard Capacity

Two mainstream capacities match low-power portable instruments

9V Cycle Life

≥500 IEC Standard Cycle Life

Stable cycle performance for long-term standby devices

9V Fast Charging

0.5C Fast Charge In 2.4 Hours

Built -ΔV & temperature charge protection required

9V Low Self-Discharge

75% Capacity After 1 Year Storage

Ultra low self-discharge formula for alarm equipment stock

9V Temperature Range

-20℃ ~ 50℃ Operating Temp

Stable output for indoor & mild outdoor detectors

9V Safety Testing

Full Safety Standard Test Passed

1hr short circuit, vibration, drop test without explosion

Factory Supply & Technical Advantages
Main Application Equipment

For Measuring Instrument Manufacturers

  • Standard R3 shell fully compatible disposable 9V battery compartment
  • 6pcs series 1.2V mini cylindrical cells, stable 8.4V output
  • Strict pack internal resistance sorting for consistent batch voltage
  • Full IEC cycle & high temp aging test reports supplied

For Safety Alarm Wholesalers

  • Ultra low self-discharge, long shelf life for inventory storage
  • Standard metal snap terminals, optional custom lead wire OEM
  • Low 2C max discharge design, match low-current alarm load
  • Complete UN38.3, MSDS, CE export certification set

Widely Used Equipment For R3 9V NiMH Packs

Digital Multimeter Wireless Microphone System Smoke Fire Alarm Detector Carbon Monoxide Sensor Portable Gas Detector Infrared Thermometer Field Measuring Instruments Wireless Remote Controller Occupancy Motion Sensor Portable Medical Detector Outdoor Mini Transmitter Industrial Gas Alarm Module

16 Years Professional 9V R3 NiMH Pack Manufacturer

9V Ni-MH Battery Pack Factory Assembly Line
  • 16+ years professional nickel metal hydride vertical integrated manufacturer
    Capacity
  • 3 production bases, total 12,000㎡ factory, 200,000 Units Daily OutputCapacity
  • Cumulative export volume of 500 million units over 16 years
  • Dedicated automatic assembly line for R3 shell 9V NiMH packs
  • Independent aging lab for self-discharge & cycle life testing
  • 160/200mAh two standard models ready in stock fast shipment
  • Provide original WJ official spec sheets & discharge curve docs
  • OEM customization: lead wire, plug, shrink label, terminal change
  • Export industrial rechargeable packs to more than 60 countries

Performance Data & Quality Assurance

All Weijiang NiMH cells are 100% tested for capacity, internal resistance and voltage before shipment. Below are representative performance curves and quality parameters for our standard NiMH cells.

NiMH Cycle Life Performance Curve

Cycle Life: 80%+ capacity after 1000 cycles

NiMH Self-Discharge Rate Curve

Self-Discharge: 84% retention after 6 months @ 20°C

NiMH Discharge Voltage Curves at Different Rates

Discharge Voltage: Stable plateau at 0.2C–2C (D-cell representative)

Parameter Standard Test Method
Cycle Life ≥1000 cycles (80% DOD) 0.5C charge / 1C discharge, 25°C
Self-Discharge ≤16% / 6 months @ 20°C Standard charge, store 6 months, measure
Operating Temp Charge 0–45°C, Discharge −20–55°C Environmental chamber test
Internal Resistance ≤30 mΩ (AA cell, typical) AC milliohm meter @ 1kHz
Capacity Tolerance ±5% of rated capacity 0.2C discharge to 1.0V

Buyer FAQ for 9V NiMH batteries

These are the questions procurement teams ask most often about 9V NiMH batteries. For company details see About Us, for documents see Certificates, and for the sourcing process see the NiMH sourcing guide.

Does Weijiang Power supply 9V NiMH batteries to EU and US buyers?
Yes. Weijiang Power has shipped NiMH batteries to 60+ countries with a focus on Europe and the United States, and provides CE (LVD), RoHS, REACH, PPWR, UL, UN38.3, MSDS and IEC 62133 documents for buyer qualification.

What is the minimum order for 9V NiMH batteries?
Standard stock has no strict MOQ and normally ships within one working day. OEM samples are prepared in 7-15 days and are free of charge, with the buyer paying freight.

Which certificates cover 9V NiMH batteries?
CE (LVD), RoHS, REACH, PPWR, BSCI, ISO 9001:2015, ISO 14001, IATF 16949, IEC 62321, MSDS, UL, UN38.3 and IEC 62133, supported by 16 patents and factory audit documents.

Can 9V NiMH batteries be customized?
Yes. Cell size, capacity, voltage, connector, PCM, label, blister card and packaging can be customized; custom battery packs and chargers take 15-25 days, standard bulk orders 7-12 days.

Last reviewed: 20 November 2026.
